Overview
Max. cutting thickness………………………………………………125m
Min. cutting length…………………………………………………300mm
Throat depth……………………………………………………….510mm
Spindle dia……………………………………………………….φ30mm
Spindle speed……………………………………………………..3450r/min
Blade dia…………………………………………………………300—400mm
Feeding speed……………………………………… 8、13.6、19.1、24m/min
Spindle power………………………………………………………11KW
Feeding motor……………………………………………………..1.5KW
Table size……………………………………………………….940×1700mm
Weight…………………………………………………………..1150Kg
Dimension……………………………………………………..196×118×160cm
In order for operator safety, this machine is equipped with 4 sets of anti-kick back fingers, upper 3 and bottom 1. And it is with chain track feeding, the feeding speed change of it is by belt and pulley. Also we have other models: QMJ154F with frequency inverter for feeding speed change; QMJ154F-T with electric-lifting for pressure lifting. Please ask for the details.
Note:all above piectures and parameters are subject to the real product. We reserve the right to improve the product.
